CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Enabling the Syslog Configuration
1. To enable Syslog, in the configuration tree select General and select enabled in the field Use of Syslog.
• Syslog Configuration is enabled in the configuration tree.
2. In the configuration tree select Syslog Configuration.
3. Define the IP address of the syslog server.
NOTE
DNS entries are possible with the latest CAN-Gateway Configurator version.
4. Select the severity level filter in drop-down list Severity level.
Defining Syslog Messages
For each syslog message the following has to be defined via action rules:
• event (trigger) to transmit a syslog message
• severity level
• payload (ASCII string)
1. Enable the syslog configuration (see
2. Define syslog messages via Action Rules:
a. Configure an IF event to set the trigger for the transmission of a syslog message.
b. As THEN action select the action type Send SYSLOG message and define the message.
3. For more information see

5.6. MQTT Configuration

NOTE
With the CAN@net NT in the CAN-Ethernet-CAN Bridge mode each device can be configured
differently. But to build a Bridge configuration all devices must be configured in one configuration
file. The configuration has to be set completely for all devices (Master, Slave 1 to 3) and then the
complete configuration has to be downloaded to each device.
Page 22 of 56
Enabling the Syslog Configuration, p.
Action Rules, p. 26.
MQTT Configuration
22).
4.02.0332.20001 Version 1.7
