7. Command Line Program

The integrated command line program CanGWfile works via USB and with the CAN@net NT also via TCP. The
command line tool is available for Windows and for Linux (cangwfile).
Output when Started Without Parameters
#### Ixxat CAN-Gateway File Utility V6.05 ####
Syntax:
cangwfile TCP <IP-address or 'any'> <command> [<file-type> <file-
name>] [<options>]
cangwfile USB <serial-no or 'any'>
name>] [<options>]
Examples:
cangwfile USB 010001A3 w CONF conf.txt
cangwfile TCP 196.168.178.20 w CXML test.cxml
cangwfile USB any wv CONF conf.txt
cangwfile TCP 196.168.178.20 re ERR error.txt
cangwfile TCP 196.168.178.20 i
cangwfile TCP any w CONF conf.txt -s010001A3
cangwfile TCP any s
Possible commands:
w - write file to target device
wv - write file with verify
r - read file from target device
re - read and erase file on target device
i - read device identification
s - scan and output found devices
h - output the historical program calls
Possible file types: CONF, ERR, IPC, CXML, HFU, LUA, LCFG, JSON
In case of 'CXML', the CONF file will be generated and additionally
written.
Possible options:
-p<password> - device password for devices with security level >= 2
-init - re-initialize the device to activate the flashed files
-reset - reset the device to activate the flashed files
-terminal - for Lua ADK outputs to the terminal
-s<serial-no> - requested serial number for TCP network devices
-dly1 / -dly2 - delays of 1/2 ms in case of communication errors
The following commands can be processed:
• reading the device identification (command i)
• reading and deleting the error memory and log files (command re)
• reading and writing a configuration (command r/w)
• writing and verifying a configuration (command wv)
• reading the file that saves all calls including parameters (command h), file is automatically stored on the PC
and can also be opened and deleted manually
• scanning for devices (command s)
File types:
