CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Event name Description
Comm. error state In Communication Error Severity it is possible to
changed to warning configure that the device changes to status warning in
defined events (see
20).
Comm. error state In Communication Error Severity it is possible to
changed to error configure that the device changes to status warning in
defined events (see
20).
CAN status byte It is possible to monitor, if the error state of the CAN
changed ports changes. A CAN status byte can be of the states
Error Active 0x00, Error Passive 0x01, Bus Off 0x02 and
Not Available 0xFF.
CAN baud-rate Only possible with Classic CAN, if automatic baud rate is
detected activated for the port.
Page 30 of 56
Communication Error Severity, p.
Communication Error Severity, p.
Action Rules
Further settings
–
–
CAN ports 1 to 4 can be selected via
checkboxes.
CAN ports 1 to 4 can be selected via
checkboxes.
4.02.0332.20001 Version 1.7
