CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Possible Entries
Column Possible entries
Rx channel CAN1, CAN2, additionally with NT 420: CAN3, CAN4
Defines the receive channel.
Rx format Standard, Extended
Defines the format in which messages are received, standard (11 bit identifiers) or extended (29 bit
identifier).
Rx ident Identifier of the message to be received
Default values If the receive message fails, the default values are transmitted instead.
Cycle time Message cycle time in units of 0.5 ms, valid values: 1–65535 (= 0.5 ms to 32767.5 ms)
Tx channel CAN1, CAN2, additionally with NT 420: CAN3, CAN4
Defines the transmit channel.
Tx Msg Format CAN (for Classic CAN messages), additionally with NT 420: CAN FD (for CAN FD messages)
as received (messages are transmitted in the same format as received) CAN FD messages can only be
transmitted on CAN3 and CAN4, and if the ports CAN3 and CAN4 are configured as CAN FD ports. If field
Tx Msg Format is left empty, and CAN port 3 or CAN port 4 are configured as CAN FD port, all messages
that are transmitted to these ports are converted into CAN FD message format.
Tx ID format Standard, Extended
Defines the format in which messages are transmitted, standard (11 bit identifiers) or extended (29 bit
identifier).
Tx ident Identifier of the transmitted message
Tx rep cnt Maximum number of transmit repetitions if the receive message is missing. Valid values: 0-65535. Value
0 sets endless transmission. If the counter expires, the cyclic message is stopped.
