CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Table 1. Data Bytes of CAN Status Message
Byte number Description
1 Error State of CAN 1
2 Error State of CAN 2
3 Error State of CAN 3
4 Error State of CAN 4
5 Global device state
6 Configuration state
7 Application state
8 Action Rules state
Table 2. CAN Error State in Bytes 1-4 of the CAN Status Message
Error state
0
1
2
3
255
Table 3. Possible States in Bytes 5-8 of the CAN Status Message
State Description
1 Error occurred
2 Warning occurred
3 Module in state preoperational
4 Module in state configuring
5 Module in state operational
6 Module is not existent
Testing IF Events
To test if an IF event occurs, the terminal window can be used.
1. Define an action rule (see
2. In column THEN action select action type Write a terminal message.
3. Define the payload of the terminal message in field Payload and click button OK.
4. Click button Terminal to open the terminal window.
• If the defined IF event occurs, the defined message is written to the terminal window.
Verify Configured Action Rules
1. Open menu View and select Show status window.
• Status window is displayed in the CAN-Gateway Configurator.
2. Click button Verify.
• Status, errors and warnings are showed in the status window.
Page 32 of 56
Possible states
See table CAN Error State in Bytes 1-4 of the CAN Status Message (page 32)
See table Possible States in Bytes 5-8 of the CAN Status Message (page 32)
Description
Error active
Error passive
Bus off
Stopped
CAN not available
Defining a Rule, p. 27).
Action Rules
