Playback

Playback can be accessed in three ways:
• By selecting Play Recording from the drop-down menu on the Main
menu. The Play Recording menu item will not be available if you have
not first created a recording.
• By selecting Play Recording from the drop-down menu on the Diagnos-
tics Menu.
• By touching the View Results button on the Record screen (Figure 9.2).
The recording file plays back at a rate which simulates the rate at which it originally
came from the vehicle bus.
To play back an existing recording:
1
Start at the Main Menu.
Figure 9.6
2
Select Play Recording.
Main Menu Showing the Drop-down Menu
PRO-LINK
®
Edge Hardware and Software User's Manual 185
- Utilities Overview
