Pre-Boot Checks
Error!
No CPU 1
Check that processor is
correctly installed in socket 1.
Error!
CPU Freq
Ensure that the two processors
installed are the same speed
(frequency).
Error!
Power supply
Check power supply and
power cable connections.
Error!
BIOS
Flash new BIOS or start system
using crisis switch (system board
switch 10).
3 Troubleshooting Your HP PC Workstation

Using HP MaxiLife to Diagnose Problems

Using HP MaxiLife to Diagnose Problems
Your HP LCD can help you to diagnose problems with your PC
Workstation, even when you are unable to get your system and monitor
working properly.
When you press your PC Workstation's on/off button, HP MaxiLife will
check your system before it initiates the start-up sequence. You will see
one of the following screens on the LCD as these checks progress:
Error!
CPU Socket 2
Check that a processor or
terminator is correctly installed
in socket 2.
Error!
CPU Type
Ensure that the two processors
installed have the same cache
voltage.
Error!
Power
Check that configuration of
VRMs and terminators is correct
or that the power supply is
properly connected.
Error!
No Video
Check that graphics card is
installed correctly.
28
English
Error!
Power CPU 1
Check installation of VRM 1.
Check installation of VRM 3.
Error!
Power Cache
Ensure that VRM is correctly
Check system board.
installed in VRM 2 socket.
Error!
RAM type
Check that RAM types
installed are compatible.
HP KAYAK XU
No errors occurred during pre-boot.
POST is initiated.
Error!
Power CPU 2
Error!
Board PLL
Error!
No RAM
Check memory installation.
