Functions and Measurements
Files Operation

Saving a File

C A U T I O N
98
The analyzer allows you to save files (states, traces, limits or
screens) to a USB storage device (USB/), or internal storage (INT/).
The following is an example of how to save a trace to internal
storage (INT/).
1 Select the save destination for the file. This example will select the
internal storage (INT/):
Press File > Directory > Memory Type INT
Press Return > Save as, the pop-up window displays for your further
2
setting.
3 Edit a file name.
A file name can consist of letters and digits. A single key stroke on
the numerical keypad inputs a digital number; and consecutive key
stroke selects and inputs a letter.
4 Rotate the knob to choose the file type you need.
Press Enter to save the file. The file will be saved immediately and
5
"File saved" will be shown in the status bar.
When saving a file to a USB storage device, do not disconnect the USB
device during the save operation. To do so may cause unexpected data
loss.
Quick Saving a File
Press [Save] to quickly save a trace or a screen to either the local
memory or an external USB device, depending upon the setup of
the save path.
Refer to the steps for saving a trace/screen:
Press File > Setup > Qsave Type to set the quick save file type.
1
Press File > Directory > Media Type to select the file directory.
2
Press Return > Save to save a trace or a screen copy to the
3
pre-defined memory. The trace or screen will be automatically
assigned with a default file name. A trace will be assigned with a
file name, such as HYTRACE, HYTRACE_1, and consecutive
