SYSTEM CONFIGURATION

SHIP'S MAINS
100/115/220/230 VAC
1 , 50/60 Hz
SHIP'S MAINS
12/24 VDC
* For 12 VDC ship's mains,
DC-DC converter is
required to use PP-510.
Distress Message Controller
** = Mandatory for EGC operation as required by IMO RES. A.664(16).
CATEGORY OF UNITS
Unit Category
Terminal Unit Protected from weather
Antenna Unit Exposed to weather
Other Units Protected from weather
viii
TERMINAL UNIT
AC-DC Power Supply
PR-240-CE
Printer**
PP-510
Mini Keyboard
DMC-5
Navigator
ANTENNA
UNIT
IC-115
IC-215
GPS receiver
OP16-24
JUNCTION
BOX
IC-315
DGPS
EGC Printer**
PP-505
Personal
Computer
(PC/AT compatible)
Shipboard LAN (Ethernet)
Distress Alert/
Received Call Unit
IC-305
Alarm Unit
IC-306
: Standard Supply
: Option
: Local Supply
24 VDC
