1. OPERATIONAL OVERVIEW
1.5

Standby Display

After the equipment is turned on and the diagnostic test has been conducted, the
standby display appears, showing the system status monitor. The system status
monitor provides various operating information. For a detailed description, see
paragraph 8.4.
File
Current State: IDLE
DCE F15 Ver. ##
##: Program Version No. of RF CON Board
After the diagnostic test has been completed, the equipment automatically starts
synchronizing itself with a satellite. When the indication "Retuning" is replaced
with " SYNC(NCS), the synchronization process is completed. Then, you are
ready to receiving EGC messages. For further details see paragraph 2.4.
Note: When the caution shown below appears, it is necessary to change the
LES ID in the distress alert setup to match current ocean region. For
further details, see paragraph 6.2.
1-8
Edit Transmit EGC
Date 02-02-25
Time 01:32 (UTC)
Position LAT 34:30.00N
LON 135:00.00E
Waypoint LAT
LON
Course 345.5 DEG
Speed 10.2 KTS
Current NCS 344 (IOR) LOGOUT
Current Channel NCS CC
Current TDM NCS CC
MES Status Idle
GPS Status ****
DCE Memory 32818 Bytes free
Pre-set LES ID for DISTRESS ALERT is invalid in the present ocean region.
Please input preferred LES ID in the [Distress Alert Setup] menu.
Reports Logs Options
BBER
C/N
Send Level
Rx AGC Level
REF Offset Freq
Synthe Local
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
Retuning
NCS: IOR LOGOUT
Standby display
CAUTION
Setup Position StopAlarm
IMN: 443156710
000
OK ( 0 dB)
OK ( 0)
OK (254)
OK ( 0 Hz)
OK
OK
68.2 DEG
232 DEG
1.9 KTS
02-02-25 01:32 (UTC)
LAT: 34:30.00N
LON: 135:00.00E
