Using A Pc (Local Supply); Installing Software - Furuno Felcom 15 Operator's Manual

1.8

Using a PC (local supply)

When using a PC as a sub terminal, the optional FD-ROM is required. The sub
terminal only functions for communications; initial settings, etc. are conducted
from the main terminal.
FD-ROM
Code No.: 004-438-920
Type:
PC requirements
OS: Windows 98, 2000, ME, XP
Floppy disk drive
1.8.1

Installing software

After installing the equipment, install the FELCOM 15 software (F15PC) in the
PC as follows:
1. Turn on the PC.
2. Insert the FD-ROM, which contains the FELCOM 15 software, in the floppy
disk drive.
3. Create a folder where to store the application files.
4. Copy the contents of the FD-ROM to the folder.
Note: Create a shortcut of the FELCOM 15 icon to easily start up the FELCOM
15 from the desktop.
16-5-0164
1. OPERATIONAL OVERVIEW
1-15
