Furuno FAR-3220-NXT Installation Manual

Chart radar
Hide thumbs Also See for FAR-3220-NXT:
Table of Contents

Advertisement

Quick Links

FAR-3210(-BB)/3220(-BB)/3310/3320/
Model
SAFETY INSTRUCTIONS ........................i
SYSTEM CONFIGURATION ..................iii
EQUIPMENT LISTS..............................viii
1. INSTALLATION...............................1-1
1.1 Antenna Unit .......................................1-1
1.2 Monitor Unit.........................................1-7
Trackball Control Unit .........................1-7
1.4 Power Supply Unit ............................1-10
1.5 Processor Unit ..................................1-11
1.6 Sensor Adapters (option) ..................1-12
1.7 Intelligent HUB (option).....................1-13
1.8 Switching Hub (option)......................1-15
1.9 Junction Box (option) ........................1-15
2. WIRING............................................2-1
2.1 Overview .............................................2-1
2.2 Antenna Unit .......................................2-4
2.3 Processor Unit ..................................2-12
2.4 Power Supply Unit ............................2-22
2.5 Monitor Unit.......................................2-26
2.6 Sensor Adapters (option) ..................2-27
2.8 Junction Box (option) ........................2-48
2.9 Intelligent HUB (option).....................2-49
(option)..............................................2-50
2.11 VDR Connection ...............................2-54
Menu3-1
3.2 How to Align the Heading ...................3-1
3.5 Dual Radar Display .............................3-3
3.6 Other Settings .....................................3-6
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
FAR-3220-NXT(-BB)/3320-NXT
www.furuno.com
CHART RADAR
(Product Name: Marine Radar)
ECDIS and Radar3-13
3.12 Web Setting Menu ............................3-16
4. INPUT/OUTPUT DATA ...................4-1
4.1 Processor Unit ....................................4-1
4.2 IEC 61162 Sentences .........................4-2
PACKING LISTS ................................. A-1
OURLINE DRAWINGS........................ D-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAR-3220-NXT and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno FAR-3220-NXT

Summary of Contents for Furuno FAR-3220-NXT

  • Page 1: Table Of Contents

    Installation Manual CHART RADAR FAR-3210(-BB)/3220(-BB)/3310/3320/ Model FAR-3220-NXT(-BB)/3320-NXT (Product Name: Marine Radar) SAFETY INSTRUCTIONS ......i 3.7 Network Transmission Setting Between ECDIS and Radar3-13 SYSTEM CONFIGURATION ....iii 3.8 How to Set the Forwarding Distance ...3-13 EQUIPMENT LISTS......viii 3.9 Synchronization With Ship’s Clock ...3-14 3.10 How to Change the Display Color for...
