System Status Monitor

The system status monitor, which is always displayed, provides date, time,
equipment status and navigation data.
File
Current State: IDLE
DCE F15 Ver. ##
##: Program Version No. of RF CON Board
Interpreting the system status monitor
Date:
Time:
Position:
Waypoint:
Course:
Speed:
Current NCS:
Current Channel:
Current TDM:
MES Status:
GPS Status:
8-6
Edit Transmit EGC
Date 02-02-25
Time 01:32 (UTC)
Position LAT 34:30.00N
LON 135:00.00E
Waypoint LAT
LON
Course 345.5 DEG
Speed 10.2 KTS
Current NCS 344 (IOR) LOGOUT
Current Channel NCS CC
Current TDM NCS CC
MES Status Idle
GPS Status ****
DCE Memory 32818 Bytes free
System status monitor display
Current date
Current time
Own ship's L/L position (either manual entry or
automatic input by navigator)
L/L position of destination waypoint set on navigator
Course
Ship's speed
NCS your vessel is logged in with
Channel in use
Channel TDM
Operational status of MES
Receiving signal status from GPS receiver.
CST: Cold Start
ACK:
IMP:
INT:
ALM:
2D, 3D: Position-fixing method by 2D or 3D
Reports Logs Options
BBER
C/N
Send Level
Rx AGC Level
REF Offset Freq
Synthe Local
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
Retuning
NCS: IOR LOGOUT
Acquired; Almanac data acquired
Impossible; cannot receive GPS signal
Interrupted; object interfering with reception
of GPS signal
Receiving the almanac
Setup Position StopAlarm
IMN: 443156710
000
OK ( 0 dB)
OK ( 0)
OK (254)
OK ( 0 Hz)
OK
OK
68.2 DEG
232 DEG
1.9 KTS
02-02-25 01:32 (UTC)
LAT: 34:30.00N
LON: 135:00.00E
