• JTAG ICE 14-pin header
• USB cable
Traditional mechanical switches for changing the board's factory setup
have been removed in favor of I
remaining mechanical switches are the JTAG switches, boot mode switch,
and push buttons. The JTAG switches are provided for setting up sin-
gle-processor JTAG communications or multiple-processor
configurations.
For information about the hardware components of the EZ-KIT Lite,
refer to
ADSP-BF609 EZ-KIT Lite Bill Of
Purpose of This Manual
The ADSP-BF609 EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board). The text
describes operation and configuration of the board components and pro-
vides guidelines for running your own code on the ADSP-BF609 EZ-KIT
Lite. Finally, a schematic and a bill of materials are provided for reference.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture,
instruction set, and C/C++ programming languages.
Programmers who are unfamiliar with Analog Devices processors can use
this manual, but should supplement it with other texts (such as the
ADSP-BF60x Blackfin Processor Hardware Reference and Blackfin Processor
Programming Reference) that describe your target architecture.
ADSP-BF609 EZ-KIT Lite Evaluation System Manual
2
C controlled software switches. The only
Materials.
Preface
xiii
Need help?
Do you have a question about the ADSP-BF609 EZ-KIT Lite and is the answer not in the manual?
