Purpose of This Manual
• High-Speed Converter (HSC) Evaluation Board Interface
40-pin, right angle, 0.1 in. spacing, female socket to con-
nect to Analog-to-Digital Converter (ADC) boards
40-pin straight, 0.1 in. spacing header to connect to Digi-
tal-to-Analog Converter (DAC) boards
Switch for clock routing and direction selection
RJ45 with Serial Peripheral Interconnect (SPI) to configure
converter registers
• LCD Interface
32-pin, right angle FLZ-type connector to connect to LCD
boards
• SMT Footprint Area
1206 and 805 footprints
SOIC24 and SOIC20 footprints
Purpose of This Manual
The ADSP-BF53x EZ-Extender 1 Manual describes the operation and con-
figuration of the components on the board. A schematic and a bill of
materials are provided as a reference for future ADSP-BF53x Blackfin pro-
cessor board designs.
Intended Audience
This manual is a user's guide and reference to the ADSP-BF53x
EZ-Extender 1. Programmers who are familiar with the Analog Devices
Blackfin processor architecture, operation, and development tools are the
primary audience for this manual.
vi
ADSP-BF53x EZ-Extender 1 Manual
