Default Configuration
The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human body
and equipment and can discharge without detection. Permanent damage may
occur on devices subjected to high-energy discharges. Proper ESD precau-
tions are recommended to avoid performance degradation or loss of function-
ality. Store unused EZ-KIT Lite boards in the protective shipping package.
Figure 1-1 shows the default jumper and switch settings and LED used in
installation. There are four nylon standoffs in a bag included in the box.
They can be installed in the four corner mounting holes (
) if desired. Place the nylon standoff in the hole and tighten a hex nut
MH9
on each. Confirm that your board is in the default configuration before
using the board.
Figure 1-1. EZ-KIT Lite Hardware Setup
1-4 ADSP-BF609 EZ-KIT Lite Evaluation System Manual
, , ,
MH1 MH7 MH8
