Power-On-Self Test

Part numbers for Samtec standard, off the shelf link port cables can be
found in Link Port /JTAG Connectors (J3 and
For more information about emulators, contact Analog Devices or go to:
http://www.analog.com/processors/tools
Power-On-Self Test
The Power-On-Self-Test Program (POST) tests all EZ-KIT Lite peripher-
als and validates functionality as well as connectivity to the processor.
Once assembled, each EZ-KIT Lite if fully tested for an extended period
of time with POST. All EZ-KIT Lite boards are shipped with POST pre-
loaded into one of their on-board flash memories. The POST is executed
by resetting the board and pressing the proper push button(s). The POST
also can be used as a reference for a custom software design or hardware
troubleshooting. Note that the source code for the POST program is
included in the EZ-KIT Lite installation directory along with the
file, which describes how the board is configured to run
readme.txt
POST.

Expansion Interface III

The Expansion Interface III (EI3) allows an Analog Devices
®
EZ-Extender or a custom-design daughter board to be tested across vari-
ous hardware platforms that have the same expansion interface.
The EI3 implemented on the ADSP-BF609 EZ-KIT Lite consists of five
connectors, ,
P1A
ity of the processor's signals. For pinout information, go to
EZ-KIT Lite Schematic. The mechanical dimensions of the expansion
connectors can be obtained by contacting
For more information about daughter boards, visit the Analog Devices
Web site at:
http://www.analog.com/processors/tools
1-20
, , , and
P1B P1C P2A P3A
ADSP-BF609 EZ-KIT Lite Evaluation System Manual
P8).
.
. The connectors contain a major-
Technical Support.
.
