Ref. Qty. Description
28 1 DB9 9PIN CON038
29 1 RJ11 4PIN
CON039
30 3 DIP2 SWT020
31 6 IDC 2X1 IDC2X1
32 1 3A RESETABLE
FUS004
33 6 IDC 2PIN_-
JUMPER_SHORT
34 1 PWR .65MM
CON045
35 1 USB_MINI-AB
5PIN CON052
36 4 MOMENTARY
SWT024
37 1 ROTA-
RY_ENC_EDGE
SWT025
38 2 IDC 7x2
IDC7x2_SMTA
39 1 ROTARY SWT027
40 1 ERM8 10X2
ERM8_10X2_SMT
41 1 ERF8 10X2
ERF8_10X2_SMT
42 1 RJ45 W/LEDS
CON065
43 1 SD_CONN 8-BIT
CON067
ADSP-BF609 EZ-KIT Lite Evaluation System Manual
ADSP-BF609 EZ-KIT Lite Bill Of Materials
Reference Manufacturer
Designator
J2 NORCOMP
J4 TYCO
SW3-SW5 C&K
P10-P15 FCI
F1 TYCO
SJ1-SJ6 DIGI-KEY
P18 DIG
P7 MOLEX
SW6-SW8,SW10 PANASO-
NIC
SW9 PANASO-
NIC
P1,ZP1 SAMTEC
SW2 COPAL
P8 SAMTEC
J3 SAMTEC
J1 PULSE
ENG.
J5 MORETHA-
NALL
Part Number
191-009-213-L-571
5558872-1
CKN9064-ND
90726-402HLF
SMD300F-2
S9001-ND
CP1-023-ND
56579-0576
EVQ-Q2K03W
EVQ-WKA001
TSM-107-01-T-DV-A
S-8110
ERM8-010-01-S-D-RA-TR
ERF8-010-01-S-D-RA-L-TR
J0011D21BNL
MHC-W21-601-LF
A-3
