Product Overview
• Controller Area Network (CAN)
• NXP TJA1041
• RJ-11 connector
• Debug interface
• JTAG header for use with ADI emulators
• Standalone debug agent
• LEDs
• Eight LEDs: one power (green), one board reset (red), one
temperature limit (amber), Ethernet speed (green), and four
general-purpose (amber)
• Push buttons
• Four push buttons: one reset, one wake, and two IRQ/flag
• Expansion Interface 3 (EI3)
• Next generation of the expansion interface design, provides
access to most of the processor signals
• Power supply
• CE approved
• 5V @ 3.6 Amps
• Other features
• Link port connectors
• SD/MMC memory connector
• Rotary encoder
• MP JTAG in and out connectors
• 0.05-ohm resistors for processor current measurement
xii
ADSP-BF609 EZ-KIT Lite Evaluation System Manual
