wwcomplements AP & EU
Section:
HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
INSTALL MOUNTING BRACKETS
NOTE: Single-Sided Corridor
Screen - Solid (MHWBLSS) is
shown as Example.
A3
A4
STEP 1: Attach Mounting Brackets to the screen as shown and secure it using Screws provided.
Installation Guides
A1
INSTALL SCREEN ASSEMBLY
A4
STEP 2: Mount the Screen Assembly to Connecting Tubes by aligning the Assembly to the
Pilot Holes. Secure the Assembly using Screws provided.
Date:
Jan 2021
Page No:
2 of 2
WWC_105
NOTE: Control Box and
Wires are Hidden for
Illustration Purpose.
