Teknion Single-Sided Rectangular Worksurface Installation Manual page 68

wwcomplements AP & EU
Section: HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
Single-Sided Spine Tray - Low Capacity (MHWBFSL/EHWBFSL), Single-Sided
Spine Tray - Mid Capacity (MHWBFSM/EHWBFSM), Single-Sided Spine Tray -
High Capacity (MHWBFSH/EHWBFSH)
A1
Installation Guides
NOTE:For WWComplements
Europe (EU) products starts with
EH and for Asia Pacific (AP)
starts with MH.
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
A3
Date: Jan 2021
WWC_114
Part and Product Identification
A1 - Spine Cable Tray, Low Capacity
(A16-9436) x1
A2 - Spine Tray Cover, Low Capacity
(N01-5180) x1
A3 - Spine Tray Mounting Bracket, Low Capacity
(A16-9438) x2
A4 - 1/2" Diameter x 1/8" Thick Circular Rare
Earth Magnet (D03-0059) x 4
A5 - M6 x 16mm JCBC Screw (E01-1409) x4
B1 - Spine Cable Tray, Mid Capacity
(N01-5178) x1
B2 - Spine Tray Cover, Smooth Felt Pet
(F03-0925) x2
B3 - Spine Tray Mounting Bracket, Low Capacity
(N01-5174R/L) x1
B4 - M6 x 16mm JCBC Screw (E01-1409) x4
C1 - Spine Cable Tray, Mid Capacity
(N01-5175) x1
C2 - Spine Tray Cover, Smooth Felt Pet
(F03-0925) x2
C3 - Spine Tray Mounting Bracket, Low Capacity
(N01-5174R/L) x1
C4 - M6 x 16mm JCBC Screw (E01-1409) x4
Page No: 1 of 5
Rev. No: 0
