wwcomplements AP & EU
Section:
HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
Anti-Collision
Dongle
NOTE: Make Sure the Anti- Collision
Dongle is attached to the Control Box.
D8
D3
STEP 15: Plug Wires and Secure Switch with screws as shown above. Make the connections. Make Sure the Anti Collision Device is attached to the Control Box.
Installation Guides
ATTACH SWITCH AND WIRE MANAGEMENT
Date:
Jan 2021
Page No:
WWC_102
NOTE: Only install one Switch to
avoid damage when flipping the table
assembly.
13 of 17
D3
