Teknion Single-Sided Rectangular Worksurface Installation Manual page 143

wwcomplements AP & EU
Section: NAVIGATE WORLDWIDE FRAMES AND WORKSURFACES
PREVIEW
1.1.9.4
1.1.9.5
1.1.9.6
1.1.9.7
1.1.9.8
1.1.9.9
1.1.9.10
1.1.9.11
Installation Guides
Part & Product Identification
DESCRIPTION PART NUMBER QTY.
(550105) 3/16" WIRE
CLAMP, YH ELECTRIC B02-0598
TABLE
(690247) #10 PAN QUAD
E01-1009
SCRW, 2 IN L
(690123-XM) FLAT
QUAD WD. SCREW 6 X E04-0090
5/8 TYP A ZINC
(550092) CABLE CLAMP
B02-0558
3/8 NYLON 3366 BLK
LEVELLER, LOW
PROFILE, LVWR1 D06-4088
(330020-50)
(P-914759) LINAK
MEMORY 90 DEG. A16-3970
MOUTING BRKT
(720025) WD SCREW
PAN QUAD #8x5/8" E04-0091
BLACK OXIDE
M5x0.8-12 mm Phillips Flat
E01-1289
Head Screw Black Oxide
PREVIEW
2
1.1.9.12
2
1.1.10
4
1.1.11
2
1.1.12
4
1.1.13
1
1.2
2
4
Date: Jan 2020
WWC_301
DESCRIPTION PART NUMBER QTY.
#8 X 1 1/4 WOOD
SCREW, PAN HEAD,
E04-0074
QUADREX DRIVE,
ZINC
NAVIGATE DIGITAL
N09-8183
SWITCH
NAVIGATE SIMPLE
N09-8192
SWITCH
Display Switch with
Up/Down Memory N09-5600
(55DPF1C00012016)
(P-DPF1K00-010006)
LINAK
N09-5796
UNDERSURFACE
UP/DOWN SWITCH
COMPLEMENTS CABLE
YEYA01
ORGANIZER
Page: 3 of 11
2
1
1
1
1
1
