Teknion Single-Sided Rectangular Worksurface Installation Manual page 119

wwcomplements AP & EU
Section: SCREENS
Description:
WWCOMP HA TABLES - AP & EU
Infinity Desk Edge Screen, For HAT, WWComplements(MYWXD/EYWXD)
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
NOTE:For WWComplements
Europe (EU) products starts
with EH and for Asia Pacific
(AP) starts with MH.
Installation Guides
NOTE:EYWXD1112 is shown as
Example.
Date: Jan_2021
WWC_202
Part and Product Identification
A1 - Infinity Desk Edge Screen
(N01-5841) x1
A3 - Screen Mounting
A2 - Screen Mounting
Bracket - L (A16-9520L) x1
Bracket - R (A16-9520R) x2
A4 - #10 X 0.875", A5 - Hex Nut Keps Zinc
Screw Washer (Hex Nut) x6
(E07-0077) x6
A6 - Plastic Spacer
(B10-0521) x2
Page No: 1 of 5
Rev. No: 0
