Teknion Single-Sided Rectangular Worksurface Installation Manual page 36

wwcomplements AP & EU
Section: HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
ATTACH BASE LINK BRACKET
A3
STEP 1: Attach the Base Link Bracket to the Connecting Tube on the frame. Secure it using the
Screws provided.
Installation Guides
A2
A3
NOTE: Feet, Control Box
and Wires are Hidden for
Illustration Purpose.
ATTACH BASE LINK COVER
STEP 2: Attach the Base Link Cover to the Bracket by placing it on the bracket.
Date: Jan 2021 Page No: 2 of 2
WWC_103
A1
