Teknion Single-Sided Rectangular Worksurface Installation Manual page 51

wwcomplements AP & EU
Section: SCREENS
Description: WWCOMP HA TABLES - AP & EU
Double-Sided Spine Screen - Solid (MHWBCTS/EHWBCTS)
Double-Sided Spine Screen - Framed Fabric MHWBCTF/EHWBCTF)
Double-Sided Spine Screen - Beveled Fabric (MHWBCTC/EHWBCTC)
D2
D3
Installation Guides
A
D1
Date: Jan_2021
WWC_108
Part and Product Identification
A - Solid Screen
(C07-7463) x1
(Shipped with MHWBCTS/EHWBCTS)
B - Framed Screen Assm.
(N09H-0270) x1
(Shipped with MHWBCTF
/EHWBCTF)
C - Beveled Fabric Screen Assm.
(N09H-0269) x1
(Shipped with MHWBCTC
/EHWBCTC)
D1 - Screen Mounting Brkt. D2 - Screen Mounting Brkt.
(A25-0757) x2 Cover (A25-0758) x2
D3 - Bottom Spacer D4 -
(A16-9465) x2
Chrome (E01-1409)
D5 -
M6 x 25mm Screw
D6 -
x2
Chrome (E01-1408)
Connector Nut
Chrome (E01-1409)
Page No: 1 of 4
Rev. No: 0
M6 x 16mm Screw
x2
M6 x 15mm Joint
x2
