Teknion Single-Sided Rectangular Worksurface Installation Manual page 60

wwcomplements AP & EU
Section: HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
INSTALL HORIZONTAL COVER
A2
A3
STEP 1: Attach Horizontal Cover to Connecting Tube then secure it using the Screws
provided.
Installation Guides
NOTE: Control Box and
Wires are Hidden for
Illustration Purpose.
A1
INSTALL VERTICAL COVER
A2
A2
STEP 2: Route electrical wire then install Vertical Cover as shown.
Date: Jan 2021 Page No: 2 of 2
WWC_111
A1
NOTE: Electrical cables
and wires need to be
routed before Vertical
Cover is installed.
