Teknion Single-Sided Rectangular Worksurface Installation Manual page 55

wwcomplements AP & EU
Section: HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
End Gable (MHWBCGE/EHWBCGE)
A3
Installation Guides
NOTE:For WWComplements
Europe (EU) products starts with
EH and for Asia Pacific (AP)
starts with MH.
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
A2
Part and Product Identification
A1 - Pet End Gable Assy
(N01-5046) x1
A2 - End Gable Mounting Bracket
A1
(A16-9475) x2
A3 - End Gable with Cable Access
(A16-9477) x1
A4 - 1/2" Diameter x 1/8" Thick
Circular Rare Earth Magnet
(D03-0059) x8
A5 - #10x1/2" Tap Screw, Quad, Pan
(E01-0023) x2
Date: Jan 2021 Page No: 1 of 4
WWC_110 Rev. No: 0
