Teknion Single-Sided Rectangular Worksurface Installation Manual page 54

wwcomplements AP & EU
Section: SCREENS
Description:
WWCOMP HA TABLES - AP & EU
ALIGN AND SECURE THE BRACKET
NOTE: Make sure the
Screen is Aligned Properly.
D4
STEP 5: Make sure the Screen is Aligned Properly and Fully Tighten the Screws as Shown
above.
Installation Guides
D4
STEP 6: Attach the Mounting Bracket Cover by Sliding it onto all the 4 Mounting Bracket.
Make sure it attaches to the Stick On.
ATTACH THE MOUNTING COVER
D2
D2
Date: Jan_2021 Page No: 4 of 4
WWC_108
Stick
On
