Teknion Single-Sided Rectangular Worksurface Installation Manual page 35

wwcomplements AP & EU
Section: HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
Single-Sided Base Link (MHWBFBS/EHWBFBS)
NOTE: Control Box
and Wires are Hidden
for Illustration Purpose.
Installation Guides
NOTE:Installation for NOTE:For WWComplements
WWComplements Europe (EU) Europe (EU) products starts with
is same as Asia Pacific (AP). EH and for Asia Pacific (AP)
starts with MH.
A1
A2
Date: Jan 2021
WWC_103
Part and Product Identification
A1 - Base Link Cover
(A16-8546) x1
A2 - Base Link Bracket
(A16-8545) x1
A3 - M6 x 16mm Screw Chrome
(E01-1409) x4
Page No: 1 of 2
Rev. No: 0
