Teknion Single-Sided Rectangular Worksurface Installation Manual page 43

wwcomplements AP & EU
Section: SCREENS
Description:
WWCOMP HA TABLES AP & EU
ALIGN SCREEN ASSEMBLY
NOTE: Control Box and Wires are
Hidden for Illustration Purpose.
STEP 2: Align the Screen Assembly with the Connecting Tube on the Frame. Adjust the
Levellers by rotating if needed.
Installation Guides
STEP 3: Secure the Frame using the Screws provided.
SECURE SCREEN ASSEMBLY
NOTE: Control Box and Wires are
Hidden for Illustration Purpose.
Date: Jan 2021 Page No: 3 of 5
WWC_106
A3
