Teknion Single-Sided Rectangular Worksurface Installation Manual page 142

wwcomplements AP & EU
Section: NAVIGATE WORLDWIDE FRAMES AND WORKSURFACES
ITEM
PREVIEW
NO.
WORLDWIDE NAVIGATE HT. ADJ. TABLE
1
EUROPE/MALAYSIA BASE ONLY
1.1
1.1.1
1.1.2
1.1.3
1.1.4
1.1.4.1
1.1.4.2
Installation Guides
Part & Product Identification
DESCRIPTION PART NUMBER QTY.
YW2/YW3
Navigate World Wide Base N09-
Sub-Assy Europe 9428C\06\14
WORLD WIDE
NAVIGATE CROSS A16-8182\14
BEAM EUROPE
World Wide Navigate Leg N09-9405
NAVIGATE STRUT ALU
A25-0630-X
CAST 23
WW Compliments Navigate
N09-9427X
Programed Control Box
LINAK CONTROL BOX
2CH 220V N09-9431X
CBD6SP00020A-009
(55-0624010) RJ45
DONGLE WITH ANTI-
I04-0104
COLLISION PROGRAM
FOR LINAK ACTUATOR
ITEM
PREVIEW
NO.
1
1.1.5
1
1
1.1.6
1.1.7
2
1.1.8
WORLDWIDE NAVIGATE TABLE HARDWARE
1.1.9
2
1.1.9.1
1
1.1.9.2
1
1.1.9.3
1
Date: Jan 2020
WWC_301
DESCRIPTION PART NUMBER QTY.
Navigate Foot 23 A25-0619\23
NAVIGATE STRUT
A25-0631
COVER
MOTOR CABLE PVC
N09-8402\05
FREE, 500MM
MOTOR CABLE PVC
N09-8402\10
FREE, 1000MM
X05-0505X
KIT
M6x16 PAN HEAD
PHILLIPS MACH SCREW
92005A426
M6x1, 14mm HEX
DRIVE, FLAT HEAD
SCREW, ZINK FINISH
M6x1.0, 20mm SHCS,
ZINC
Page: 2 of 11
2
2
1
1
1
E01-1336 12
E01-1249 16
E01-1253 8
