Teknion Single-Sided Rectangular Worksurface Installation Manual page 48

wwcomplements AP & EU
Section: SCREENS
Description:
WWCOMP HA TABLES - AP & EU
Pilot
Holes
A3
A4
STEP 3: Mount the Screen assembly onto the Worksurface by aligning the Assembly to the Pilot Holes. Secure the Assembly using the Screws provided.
Installation Guides
INSTALL SCREEN ASSEMBLY
A4
A2
A2
A4
Date: Jan_2021 Page No: 3 of 5
WWC_107
NOTE: Control Box, Wires
and Connecting Tube is Hidden
for Illustration Purposes.
