wwcomplements AP & EU
Section:
HEIGHT ADJUSTABLE TABLES
Description:
WWCOMP HA TABLES - AP & EU
Single-Sided Cable Riser - Mid (MHWBECM/EHWBECM)
A1
Installation Guides
A2
A4
NOTE:For WWComplements
Europe (EU) products starts with
EH and for Asia Pacific (AP)
starts with MH.
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
Date:
Jan 2021
WWC_112
Part and Product Identification
A1 - Cable Riser Body, SS
(N01-5180) x1
A2 - Cable Riser Cover, SS
(N01-5181) x1
A3 - M6 x 16mm Screw Chrome
(E01-1409) x4
A4 - Power Bar Holder for SS
Cable Riser
(A16-8551) x1
A5 - 10-32x3/8" Sheet Metal
Screw, Truss Quad
(E07-0084) x4
Page No:
1 of 4
Rev. No: 0
