DLAP-211-JNX / DLAP-211-Nano Series

1.3 Mechanical Dimensions

All dimensions shown in millimeters (mm).
148

Figure 1-1: DLAP-211-JNX Front View

105

Figure 1-2: DLAP-211-JNX Side View

Introduction
5
