Rear Panel
J
Item Name
J CAN bus
K Serial port
L HDMI port
M USB 2.0
Introduction

Figure 1-10: Rear Panel I/O Connectors

Description
CAN 2.0B (backward compatible with 2.0A)
COM port (DB-9 connector)
RS-232/422/485 (software programmable)
HDMI 2.0 with lock
USB 2.0 OTG (Micro USB)

Table 1-3: Rear Panel I/O Connectors

DLAP-211-JNX / DLAP-211-Nano Series
K L M
