Hdmi Connectors; Usb 2.0 Otg Connector; Table 1-9: Hdmi Connector Pin Definition; Table 1-10: Usb 2.0 Otg Connector Pin Information - ADLINK Technology DLAP-211-JNX Series User Manual

1.5.6

HDMI Connectors

The rear panel HDMI connector supports HDMI 2.0.
Pin #
1
3
5 TMDS Data1 Shield
7
9
11 TMDS Clock Shield
13
15
17 DDC/CEC Ground
19

Table 1-9: HDMI Connector Pin Definition

1.5.7

USB 2.0 OTG Connector

The DLAP-211 supports a USB 2.0 OTG Micro USB Type-B con-
nection for system recovery.
Pin Signal
1 VCC_USBDev
2 USB_D1_n
3 USB_D1_p
4 USB_ID
5 GND_USBDev

Table 1-10: USB 2.0 OTG Connector Pin Information

Introduction
Signal
TMDS Data2+
TMDS Data2–
TMDS Data0+
TMDS Data0–
CEC
SCL
Hot Plug Detect
Description
USB device power
Universal Serial Bus Port 1 / USB-Client
differential pair
USB ID pin
USB GND
DLAP-211-JNX / DLAP-211-Nano Series
Pin # Signal
2 TMDS Data2 Shield
4 TMDS Data1+
6 TMDS Data1–
8 TMDS Data0 Shield
10 TMDS Clock+
12 TMDS Clock–
14 Reserved
16 SDA
18 +5 V Power
