Item Name
A Power button
B Recovery button
C Reset button
GbE connector
D
(LAN 1)
GbE connector
D
(LAN 2)
E USB 3.0
F DC connector 12V
G V-by-One connector Max. 2x 4k @30fps, 2x 1080p @60fps
D-sub 37-pin
H
connector
SCSI 50-pin
I
connector
Table 1-2: Front Panel I/O Connectors & Controls
10
Description
The power button is a non-latched pushbutton
with a blue LED power indicator. Press to power
on/power off the system. The button LED lights up
when the system is turned on. If the system
hangs, pressing and holding the button
continuously for 5 seconds performs a hard
shutdown on the system.
Press this button to force the system into recovery
mode. See Section 3.2 System Recovery.
The reset button executes a hard reset on the
system.
GbE from NVIDIA® Jetson™ TX2.
See Section 1.5 Pin Definitions.
GbE from Intel® I210.
See Section 1.5 Pin Definitions.
See Section 1.5.2 USB 3.0 Connectors.
12V DC screw-type connector.
See Section 1.5.3 12V DC Connector.
1x I2C, 1x SPI, 1x UART, 8x GPIO,
1x Relay function
2x I2C, 2x SPI, 1x UART, 8x GPIO
