2.9 AT Power Mode Switch (SW4)

The DLAP-211 is set in AT mode by default. By using the AT
Power Mode Switch (SW4), users can set the system to be pow-
ered-on with the power button.

Figure 2-5: AT Power Mode Switch (SW4)

AT mode can be configured as follows.
SW4 Auto Power On
SW4 Auto Power On
OFF Enable (Default)
2
ON Disable

Table 2-1: AT Mode Switch Configuration

28 Getting Started
