DLAP-211-
Model
JNX
Internal I/O Interface
Mini PCIe
M.2
USIM
Debug Port
Storage Devices
SATA Extention
SD Card
Power
DC Input
AC Input
Fail Reset
Power LED
Indicator
Mechanical
Antenna Holes
DLAP-211-JNX/Nano: 148(W) x 105(D) x 52(H) mm
Dimensions
DLAP-211-JNXS/JNXO/NanoS/NanoO: 148(W) x 105(D) x 64(H) mm
Weight
Mounting
Introduction
DLAP-211-JNX / DLAP-211-Nano Series
DLAP-211- DLAP-211-
JNXS JNXO
1x Mini PCIe slot
M.2 B key 2242 socket
1x USIM slot
1x debug console
1x M.2 B key supports SATA/NVME
60W AC/DC adapter
84W AC/DC adapter (optional)
Reset and recovery buttons
Power button
Gross 1.725 KG / Net 1.5 KG
Wall and VESA (DIN rail optional)
Table 1-1: Specifications
DLAP-211- DLAP-211-
Nano NanoS
1x SD
12V
4x SMA
DLAP-211-
NanoO
