IC-KP2-2HB17-2V1D
Commands
Extended commands for IQH2-... and IUH-... read/write heads
Note!
A detailed description and further commands can be found in the manual for the read/write
head.
read param (RP)
Command:
Byte
Byte 0*
Byte 1*
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Table 7.35
Response:
Byte
Byte 0*
Byte 1*
Byte 2
Byte 3
Byte 4
Byte 5
...
...
...
1)
Byte N
Table 7.36
Contents
Telegram length 00 ... FFh
Telegram length 00 ... FFh
Command code (BEh)
Reserved/Ident channel/Toggle bit
System code
Parameter type
Parameter type
not used
not used
* this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Contents
Telegram length 00 ... FFh
Telegram length 00 ... FFh
Command code (BEh)
Reserved/Ident channel/Toggle bit
Status
Reply counter
Data 00 ... FFh
Data 00 ... FFh
Data 00 ... FFh
Data 00 ... FFh
* this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Bit no.
7 6 5 4 3
<TelegramLen> (high byte)
<TelegramLen> (low byte)
1 0 1 1 1
- <Channel>
<SystemCode>
<ParamTyp> (high byte)
<ParamTyp> (low byte)
-
-
Bit no.
7 6 5 4 3
<TelegramLen> (high byte)
<TelegramLen> (low byte)
1 0 1 1 1
0 <Channel>
<Status>
<ReplyCounter>
<Data>
<Data>
<Data>
<Data>
2 1 0
1 1 0
<T>
2 1 0
1 1 0
<T>
