Setting tag type IPC03 on channels 1 and 2
Send the command change tag as an implicit command:
Ele- Implicit
ment telegram
1
2
3
4
Confirmation:
Ele- Implicit
ment telegram
1
Use
Byte 0 Command code
Byte 1 Channel/Toggle bit
Byte 2 Tag type (high byte)
Byte 3 Tag type (low byte)
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8 Command code
Byte 9 Channel/Toggle bit
Byte 10 Tag type (high byte)
byte 11 Tag type (low byte)
byte 12
Byte 13
Byte 14
Byte 15
Byte 16
...
Byte 23
Byte 24
...
Byte 31
Use
Byte 0 Command code (Echo)
Byte 1 Channel/Toggle bit
Byte 2 Status
Byte 3 Reply counter
Byte 4
Byte 5
Byte 6
Byte 7
Type Description
04h Command CT (change tag)
00h The element defines the
channel.
Toggle bit = 0
30h IPC 03
33h IPC 03
00h Not used
00h Not used
00h Not used
00h Not used
04h Command CT (change tag)
00h The element defined the
channel.
Toggle bit = 0
30h IPC 03
33h IPC 03
00h Not used
00h Not used
00h Not used
00h Not used
00h Reserved
00h Reserved
Type Description
04h Command CT (change tag)
02h Channel = element = 1
Toggle bit = 0
FFh Processing command.
01h For every ident telegram, the
value on the reply counter
increases by 1.
00h
00h
00h
00h
