Pepperl+Fuchs IC-KP2-2HB17-2V1D Manual page 45

IC-KP2-2HB17-2V1D
Commands
Read PLC5 type:
N7:0
N7:1
N7:2
N7:3
N7:4
N7:5
N7:6
N7:7
N7:8
N7:9
N7:10
N7:11
N7:12
N7:13
N7:14
N7:15
Example: Read/writ operations involving more than 114 registers
Restrictions apply to assembly instances 107d/157d and 111d/161d:
The IDENTControl Compact does not support fragmentation protocols. It is therefore not
possible to send or receive more than 114 words simultaneously. The data set must be divided
into two separate PCCC commands because instances 107d/157d and 111d/161d use more
than 114 registers.
Output
instance instance
111d
1. Command:
Message type
Write PLC5 type
2. Command:
Message type
Write PLC5 type
3. Command:
Message type
Read PLC5 type
4. Command:
Message type
Read PLC5 type
15 14 13 12 11
<WordNum> 0
<ReplyCounter>
Read data DW 1
Read data DW 1
<WordNum> 0
<ReplyCounter>
Read data DW 1
Read data DW 1
<WordNum> 0
<ReplyCounter>
Read data DW 1
Read data DW 1
<WordNum> 1
<ReplyCounter>
Read data DW 1
Read data DW 1
Input Channel size
1 2 reserv. reserv.
111d 60 60 60
Start register
N14:0
Start register
N14:60
Start register
N7:0
Start register
N7:60
10 9 8 7 6
0 1 <T> <Command>
<Status>
1 0 <T> <Command>
<Status>
1 1 <T> <Command>
<Status>
0 0 <T> <Command>
<Status>
Size needed / generated
5
Output / Input bytes
(conf.)
60 8 248 / 248
Number of registers
60
Number of registers
64 (128 bytes / 2)
Number of registers
60
Number of registers
64 (128 bytes / 2)
5 4 3 2 1 0
45
