Recalling an input preset

To recall an input preset, do the following:
1. Click the drop down arrow in the presets field. A list of presets (1 through
128) appears.
2. Scroll to and click on the desired preset number. The preset field shows the
number selected.
3. Click Recall to recall the selected preset.

Starting auto image

To start auto image, do the following:
1. Click Auto Image. The auto image feature automatically sizes and centers the
selected input image to fit the screen.

Freezing an image

To freeze an image for review or logo use, do the following:
1. Click Freeze. The image is frozen and all Picture Adjustments and Top and
Bottom Blanking fields are grayed out.
ISM 824 Integration Scaling Multiswitcher • ISM 824 Multiswitcher Software 5-25
