- Page 1 User’s Manual DISPLAY POWER Laptop VOLUME MAX/ Extron MLC 206 Extron Projector MediaLink Controller Extron IR Broadcaster IR Broadcaster System Switcher and MediaLink Accessory 68-392-02 Rev. B Printed in the USA 02 02...
-
Page 2: Front And Rear Panels
(or other device) can receive the IR signals. For some applications it may be desirable to limit the signal broadcast range. There is a connector on the IR Broadcaster for use with the standard IR Emitter. If an Emitter is... - Page 3 Using a signal with a carrier signal For most applications, a signal that already has a carrier frequency may be used with the IR Broadcaster. Use pin C from the System 5/5cr/5cr Plus or System 7SC connector, or pin A on the MLC (see diagrams on page 7), and use the IR Broadcaster’s default DIP switch settings (switch...
- Page 4 119.60 406.10 183.60 118.60 394.10 181.10 117.50 382.90 178.70 116.50 372.23 176.33 115.53 372.20 176.30 115.50 362.20 174.00 114.50 352.60 171.80 113.60 343.60 169.60 112.60 335.00 167.50 111.70 335.00 167.50 111.68 IR Broadcaster with Emitter Port • Installation & Operation...
- Page 5 57.75 35.65 Making the Cable Extron provides the 3.5 mm connectors with the IR Broadcaster, however a cable will have to be made to fit your installation requirements. Use the following information to make the cable. IR Broadcaster with Emitter Port • Installation & Operation...
- Page 6 Because there will be +12 volts on the tip (from the switcher CAUTION or the MLC) it is best to plug the cable to the IR Broadcaster first, and then into the switcher’s or MLC’s panel. If the projector has round jack marked “Wired Remote”, this may be wired to pin A.
- Page 7 To pass through an IR signal that includes a carrier signal, connect the signal wire to the pin designated for carrier and signal. If you want the IR Broadcaster to generate the carrier signal, connect the signal wire to the pin designated for signal only. COMM...
-
Page 8: Extron's Warranty
Extron’s Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:...
