Raven Command FLEX II Calibration And Operation Manual page 89

Type
NCV low flow limit - multiple
NCV low flow limit - single
NCV retransmission - multiple • Go to Diagnostics -> Diagnostic Trouble Codes
NCV retransmission - single
Notification
NCV zero flow target -
multiple
NCV zero flow target - single
Off pressure high
Diagnostics: System Diagnostics
Description
• Increase operation speed or turning rate.
• Check for correct target rate and pressure.
• Check for high NCV efficiency number.
• Check for correct tip size for desired rate,
• Check flowmeter calibration value, as it may
• Check poppets for excessive wear.
• Increase operation speed or turning rate.
• Check for correct target rate.
• Cycle power to RCM-S ECU by going to
• Replace affected NCVs. Then recalibrate NCVs
• Check for correct target rate.
• Check for correct target pressure.
• Check for electric or manual valves are
• Check strainers and check valves for
• Check for damaged pressure sensor or
• Check for correct tip size.
• Check pump for proper operation.
• Check Off Pressure Alarm % value.
Recommended Actions
Should normally be between 90 and 105.
speed, and pressure.
be too high.
-> NCV Errors -> NCV Heat Map and locate
the NCV(s) that are not green. Their numerical
locations are labeled referencing the forward
travel direction, from leftmost to rightmost
NCV along the boom. Note their location for
future reference and troubleshooting as
necessary.
Diagnostics -> Tests -> Reboot Product
Controller.
by going to Diagnostics -> Tests -> Calibrate
NCVs. If necessary, check NCV software by
going to Diagnostics -> Tests -> NCV Updates
to scan and update software on affected
NCVs.
opening correctly.
obstructions.
cabling.
DIAGNOSTICS
79
