NCV TECHNICAL SPECIFICATIONS

AIM Command FLEX™ II Nozzle Control Valve Technical Specifications
TABLE 2.
Dimensions
Power
Input/Output
Environmental
AIM COMMAND FLEX™ II NOZZLE CONTROL VALVE STATUS
FIGURE 2. Nozzle Control Valve LED
Troubleshooting: NCV Technical Specifications
Height
Width
Depth
Weight
approximately 8.0 oz.
Operating
Voltage
Max. Operating
Pressure
Operating
Conditions
Storage
Conditions
Relative Humidity
Diagnostic
LED
U.S.
2.9 in.
2.7 in.
1.6 in.
approximately 0.225
10.5 to 36 VDC nominal
105 PSI
14° to 167° F
-40° to 185° F
10 to 95%
TROUBLESHOOTING
Metric
7.32 cm
6.73 cm
40 cm
kg
724 kPa
-10 to 75° C
-40° to 85° C
87
