APPENDIX
F

WIRELESS SECTION CONTROL REMOTE OPERATION

Refer to the Section Control Remote 2.0 Operation Guide (P/N 016-0171-685) for assistance with using the Section
Control Remote 2.0 (P/N 063-0174-002).
To enable communication with the RCM-S ECU:
UT Menu
RCM - Sprayer Menu
1. Open the UT Menu and select the RCM - Sprayer Menu button.
2. Select the Tools Menu softkey along the right side of the display.
3. Select the System Settings tab along the top of the display.
4. Use the Wireless Control Mode drop-down and select the Section or NCV option.
FIGURE 1. Enable Wireless
: Wireless Section Control Remote Operation
R EMOTE CONTROL AND
A P P E N D I X F
DIAGNOSTICS
Tools Menu
User Settings
System
Settings
