Chapter 2 Introduction - Raven Command FLEX II Calibration And Operation Manual

CHAPTER
2
The Raven Rate Control Module (RCM) - Sprayer system is designed to provide rate control via an ISOBUS
universal terminal (UT).
Adding the AIM Command FLEX™ II nozzle control system to the RCM - Sprayer allows the machine operator to
monitor and control pressure independently from the application rate without additional displays, controllers, or
consoles.
This document provides information regarding the following aspects of the RCM - Sprayer and AIM Command
FLEX™ II control systems:
• Initial Setup and Navigation
• Calibration
• System Operation
• Updating Components
NOTE: Prior to using the control features with any UT display, the RCM - Sprayer and AIM Command FLEX™
II Electronic Control Unit (ECU) must be calibrated for the control system. Refer to Chapter 3, System
Calibration, for assistance with completing the initial calibration wizard.
This manual assumes that the required control hardware is already installed on supported equipment
and is properly connected. Refer to the Updates section on page 9 for installation manual resources or
contact a local Case IH dealer for additional information on supported equipment configurations.
