CHAPTER 3
If the working set is not available on the desired UT, check the other displays and use the
Transfer UT softkey to transfer the RCM - Sprayer working set.
By default, the working set will load to the first UT detected by the ISOBUS. When using
the Transfer UT softkey, the working set will automatically load to the last UT selected
unless the system requires calibration or the last UT cannot be detected within two
minutes.

UNLOCKS

NOTE: If features are unlocked after the initial calibration wizard is completed, a new
profile must be created and the calibration wizard must be completed before
the feature will be available.
An Unlocks softkey is displayed during the calibration wizard and allows the operator to activate and enable
features on the system prior to completing the wizard. This will allow the operator to properly calibrate all features
available on the system (e.g. Individual Nozzle Control, boom recirculation, etc.) before creating and completing a
profile.
Review the Feature Unlocks Tab section on page 43 for assistance with entering unlock codes.

CALIBRATION WIZARD

The following steps may help with completing the initial setup of the RCM - Sprayer
1. Turn the UT power on and allow the display to initiate the ISOBUS system.
NOTE: If properly connected and powered, the UT will automatically detect the Raven RCM - Sprayer ECU.
If the RCM - Sprayer ECU is not detected by the display terminal, troubleshoot the ECU and restart the
system. Refer to Chapter 9, Troubleshooting, for assistance with connection issues or contact a local
Case IH dealer for additional troubleshooting assistance.
2. Once the RCM - Sprayer ECU is detected, the RCM - Sprayer Menu button will display in the UT Menu.
3. Touch the Menu button to access the control system user interface.
4. The first time that the system is started on the UT, or if a new profile is created, the calibration wizard prompt
will be displayed.

MAKE, MODEL, AND BOOM CONFIGURATION

NOTE: Some sections in the calibration wizard may be pre-populated or skipped depending upon the
machine type selected or configurations automatically detected.
For factory installed systems with no field modifications,
configure most machine settings.
If not using the Auto configuration, select the correct machine make, machine model, and the boom
configuration to automatically load machine specific settings and skip some setup items. Use the
Other option only if the specific machine make and model information is not available within the
drop down options. Select
drop-down options.
12
Custom if the specific boom configuration is not available within the
RCM - Sprayer and AIM Command FLEX™ II Calibration and Operation Manual
RCM - Sprayer Menu
control system:
Auto should be selected to automatically
Unlocks
